| MOQ: | 1ユニット |
| 標準パッケージ: | エクスポート標準 |
| 配達期間: | 25日 |
| 決済方法: | T/T |
| Main size | Overall length | 15000mm |
| Overall width | 2700mm | |
| Overall height | 3100mm | |
| Loading capacity | Loading 8 units of cars. Capacity of 25Tons. |
|
| Chassis | Main beam | Material of high strength steel T700. Height 400mm. Welded by automatic submerged-processes. |
| Main cross beam | Material is high strength steel T700. Welded by automatic submerged-arc processes |
|
| Posts | Main posts | Material of high tensile steel T700. 5 pairs of each trailer |
| Side bars | Material is high strength steel T700. Multi numbers installed. |
|
| Floor | Material | Manganese steel plate floor thickness of 3mm. Multi holes designed. Yellow and red painted track. |
| Landing gear | 20T model landing gear, brand Yahua, with static capacity of 50T. Single speed linked type, operated at one side. |
|
| King pin | 2 inches size, installed on the kingpin plate. JOST brand. |
|
| Axle | 2 sets of 13T model axles. Axle beam 1840mm. Axle loading 13000kgs. |
|
| Tire | Tire sized 10R22.5, Double Star or Triangle brand. 4 sets of tires assembled with wheel rim per trailer. |
|
| Wheel rim | Sized 8.0-20, Zhengxing brand. 4 pcs of wheel rim per trailer. |
|
| Hydraulic Cylinders |
5 units (2 sets of each unit) of hydraulic cylinders installed, to lift the second floor and cars. Youggu brand. |
|
| First unit | At the front post, out&back, extend 600mm. | |
| Second unit | At the end post of gooseneck, out&back, extend 600mm. | |
| Third unit | Under the aircraft style plate, to lift single car, out&back, extend 900mm. | |
| Forth unit | At the post in front of tire, out&back, extend 900mm. | |
| Fifth unit | At the end post of trailer, only out, back by the cars' gravity, extend 1600mm. | |
| Suspension | Mechanical steel suspension system, double axles type. 4 sets of leaf springs installed. |
|
| Brake sysem | Dual line air drum brake system with T30/30 type double brake chambers on each axle. | |
| Light system | 12v/24v light system. LED lights, including side, rear, turning. |
|
| ABS system | ABS system installed, HN or Kemi brand. | |
| Others | Color optional. One set of standard tools in tool box. One bag of belts for firming the cars. |
|
